Model 10F__KS Roller Conveyor Product Information

Our roller conveyors at Ashland are one of the simplest and affordable types of material handling systems. Our 10F__KS model of roller conveyors are ideal for a product with firm and flat bottoms and damp environments, making them a unique material handling solution.

10F__KS Roller Conveyor Construction:

Roller: Model KS
Tube: 1.9""x16ga 304 stainless steel
Roller Bearing: All stainless commercial light oil
Axle: 7/16"" hex 304 stainless steel
Axle retention: Stainless steel spring
Frame: 10F: 3-1/2"" x 1-3/8"" x 11 ga. painted steel channel
Coupling: Butt plate
Roller Capacity (lbs): 245 to 260
Frame Capacity (lbs/ft): 120 on 10' support centers, 600 on 5' centers

10F__KS Roller Conveyor Configuration:

Roller Centers (in): 3, 4.5, 6
Between Frame (in): 7 to 51
Straights (ft): 5, 10
Curves (deg): 45, 90
Sleeve: Optional 1/8"" orange polyurethane
Model 10F__KS Roller Conveyor Product Information
FILTERS
1732 results
Wheel Flow Rail 10FR4G10015

10FR4G10015

Roller Conveyor 10F10KG03B22BP

10F10KG03B22BP

Roller Conveyor 10F05KG03B36BP

10F05KG03B36BP

Roller Conveyor 10F05KG03B22BP

10F05KG03B22BP

Roller Conveyor 10F10KG03B36BP

10F10KG03B36BP

Wheel Flow Rail 10FR4G6515

10FR4G6515

Roller Conveyor 10F10KG45B27BP

10F10KG45B27BP

Roller Conveyor 10F10KG03B21BP

10F10KG03B21BP

Roller Conveyor 10F05KG03B27BP

10F05KG03B27BP

Flanged Roller Flow Rail 10FRMFP3003R

10FRMFP3003R

Wheel Flow Rail 10FR1G6503

10FR1G6503

Roller Conveyor 10F10KG03B33BP

10F10KG03B33BP

Roller Conveyor 10F10KG03B27BP

10F10KG03B27BP

Roller Conveyor 10F10KG03B07BP

10F10KG03B07BP

Roller Conveyor 10F10K03B13BP

10F10K03B13BP

Wheel Flow Rail 10FRMP2503

10FRMP2503

Flanged Roller Flow Rail 10FRMFP3003L

10FRMFP3003L

Wheel Flow Rail 10FR6G10015

10FR6G10015

Wheel Flow Rail 10FR4P4015

10FR4P4015

Wheel Flow Rail 10FR4G6515PU

10FR4G6515PU

Wheel Flow Rail 10FR4G10003

10FR4G10003

Wheel Flow Rail 10FR2G6503

10FR2G6503

Wheel Flow Rail 10FR2G10003

10FR2G10003

Roller Conveyor 10F90K03B33BP

10F90K03B33BP

Roller Conveyor 10F10KG45B36BP

10F10KG45B36BP

Roller Conveyor 10F10KG03B47BP

10F10KG03B47BP

Roller Conveyor 10F10KG03B13BP

10F10KG03B13BP

Roller Conveyor 10F10K03B51BP

10F10K03B51BP

Roller Conveyor 10F10K03B22BP

10F10K03B22BP

Roller Conveyor 10F10DG03B13BP

10F10DG03B13BP

Roller Conveyor 10F05KG45B36BP

10F05KG45B36BP

Roller Conveyor 10F05KG45B13BP

10F05KG45B13BP

Roller Conveyor 10F05KG03B51BP

10F05KG03B51BP

Roller Conveyor 10F05K03B16BP

10F05K03B16BP

Roller Conveyor 10F05K03B13BP

10F05K03B13BP

Conveyor Gate 10F03KG03B22NC

10F03KG03B22NC
