Model 5F_ _T Roller Conveyor Product Information
The Model 5F_ _T roller conveyor is constructed of 4"x5.4# Painted Steel side channels, 2-5/8"x7ga Plain Stl tubing, 11/16" Hex Plain Stl roller shaft, and Butt Plate couplers. This model of conveyor rollers are compact but will convey light, medium, and heavy loads. These conveyor systems are one of the most popular handling systems on the market.
5F__T Roller Conveyor Construction:
Roller: Model T Tube: 2-5/8" O.D. x 7 ga. plain steel
Axle: 11/16" hex plain steel
Roller Bearing: Commercial Light Oil
Axle retention: Spring
Frame: 5F: 4" x 5.4# painted steel channel
Coupling: Butt plate
Roller Capacity (lbs): 587 to 850 (depending upon BF)
Frame Capacity (lbs/ft): 300 on 10' support centers, 1,550 on 5' centers
5F__T Roller Conveyor Configuration:
Roller Centers (in): 3, 4.5, 6
Between Frame (in): 10 to 51
Straights (ft): 5, 10
Curves (deg): 45, 90
Sleeve: none
