Model 14F__SG Roller Conveyor Product Information
The Model 14F__SG roller conveyor is constructed of 4"x7ga Painted Steel side channels, 2-1/2"x11ga Galv Stl tubing, 11/16" Hex Plain Stl roller shaft, and Butt Plate couplers. 14F__SG rollers are heavy duty and can conveyor heavy loads, making them one of if not the most popular handling systems around.
14F__SG Roller Conveyor Construction:
Roller: Model SG
Tube: 2-1/2"x11ga Galv Stl tubing
Axle: 11/16" Hex Plain Stl
Roller Bearing: Commercial Light Oil
Axle retention: Spring Retained
Frame: 14F: 4"x7ga Painted Steel side channels
Coupling: Butt Plate
Roller Capacity (lbs): 587 to 850
Frame Capacity (lbs/ft): 230 on 10' support centers, 1,050 on 5' centers
14F__SG Roller Conveyor Configuration:
Roller Centers (in): 3, 4.5, 6
Between Frame (in): 7 to 51
Straights (ft): 5, 10
Curves (deg): 45, 90
Sleeve: none online
